The outdoor basketball court has basketball courts made of soil, cement, asphalt, plastic flooring, and other materials. And some game venues also use sports wood flooring to lay the basketball court floor. Nowadays, in remote areas such as rural areas, it is generally possible to see basketball courts made of soil or cement. Asphalt flooring is more commonly used in some small units, while plastic flooring is only used in schools, sports venues, communities, sports centers, etc. due to high construction costs and good performance.
Basketball court simulation diagram
This basketball court requires the installation of 6 light poles, using a total of 6 280W LED Stadium Light. The lights cover the entire court without any dark areas, with high brightness and uniformity, and the illumination meets training requirements
Lighting direction diagram
Pseudo color representation diagram
This venue uses a total of 6 pcs LED Stadium Light. . After all are lit up, the average illuminance of the venue can reach 150 lux or above, with a uniformity of 0.60 or above, and a glare index of less than 30.
Average illuminance: 193lux; Minimum illumination: 116lux; Maximum illumination: 347lux; Site uniformity: 0.60
