- PFF: 1632μmole/s(480W),2176μmole/s(640W),2720μmole/s(800W),3264μmole/s(1000）
- Full-spectrum design, suitable for the growth of all plants;
- The photosynthetic efficiency is as high as 2.8μmole/J, high light efficiency, and more power saving;
- Maintenance-free, reducing the cost of use;
- Long service life, 3 years warranty for the whole lamp.
Samsung lm301b & Osram 660nm
Use Samsung Im301b with the most efficient umol output on the market and Osram 660nm lamp beads (optional), place them evenly, give you better light distribution, and create a uniform plant canopy. According to customer’s requirement, we can also use Im301h and cree xpe leds or add UV and IRled. At the same time, we also have more high-PPF light efficiency solutions for customers to choose from.
Excellent Thermal Performance
Unique appearance and sturdy design, using 6063 pure aluminum material, each radiator weighs more than 1KG, to ensure that the lamp body has a good heat dissipation effect, so that the lamp body can still maintain a relatively low temperature after a long time of work, after 30,000 hours of use The light attenuation is less than 3%, which ensures the long life of the lamps and meets the stringent requirements of commercial planting projects for lamps.
Inventronics Drive Power
Use the Inventronics drive power supply, which is more suitable for commercial engineering use, with a rated input voltage of 120-277V, and we can also provide 277-480V input voltage to meet the needs of larger engineering projects. In addition, we can also provide extension cables between the driver and the light, because some growers prefer to install the driver outside the grow room, or not installed on the light fixture, or on the side.
This 640W grow light is equipped with an external RJ14 interface and cable, compatible with our controller, this controller allows you to connect up to 200 grow lights, dimming, timing, Turn on or off the lamps, allowing you to control the plant growth lights freely, which brings great convenience to commercial growers.
|Power||480W ± 5%|
|640W ± 5%|
|80OW ± 5%|
|1000W ± 5%|
|PPF:||Up to 1632umol/s||Up to 2176umols||Up to 2720umols||Up to 3264umolls|
|Efficiency||Up to 2.8umolJ||Up to 2.8umolJ||Up to 2.8umol/J||Up to 2.8umolJ|
- Product working voltage is AC100~277V,50/60Hz，Please do not exceed the working voltage range.
- The lamp cannot be used in violation of any fire regulations.
- Input product line, brown is “L”, blue is “N”, yellow-green is GND.
- Be sure wiring is closed and prevent leakage when installing.
- Be sure to disconnect power before installing, don’t construction with electricity.
|Net Weight Of The Product:||36.2lbs/16.5kg|
Gross Weight Of Product:
|Heat Dissipation||100% passive|
|CCT:||Standard 3000k & 660nm|
|PPFD @18″:||896umol/m2/s avg. over 4×4′|
|PPFD@24″:||750umol/m2/s avg. over 4×4″|
|Installation height:||More than 30-60cm|
|Input Power:||Standard 680W±5%|
|Light Modulator:||0-10v Dimming knob|
|Power Cord Length:||Standard 1.5m|
Advantages for dimmable electronic ballast products
No switchboard is required.
Easy and safe installation (low voltage device)
prevent short circuit
Dual Temperature Safety Features
Control up to 100 horticultural lights
Display output as W or %
Temperature setting automatic shutdown
