IP65 LED Tunnel Light
- Housing adopted the extruded aluminum technology
- High lumen: 120lm/w
- Chip: Philips 3030 LED
- Temperature:less than 65 degree
- Energy saving system, saving 80% energy
- Ambient temperature:-30-45degree Body
- Good Color Rendering
- Warm and cold color temperature are available
- Good heat sink design
- CE RoHS Approved
- Beam Angle: 60°,60*120°,80*155°
- Warranty: 5 years
Wandan LED Product Details
Applications: For factory, station, tunnel, control room, transformer room etc.
Manufacturer of IP65 Extruded Aluminum LED Tunnel Light . Available with 50W To 250W power supply and -40 degrees C to +50 degrees C operating temperature. Color temperature ranges up to 6500 degrees K. Suitable for wall washer, high bay and outdoor lighting applications. Vendor managed inventory (VMI) programs offered. Stock items available. CSA approved. RoHS compliant. Kanban and JIT delivery. Five year warranty.
| Model： | WD-YSLTL50W-B01 | WD-YSLTL100W-B02 | WD-YSLTL150W-B03 |
| Lamp type： | Outdoor | Outdoor | Outdoor |
| Rated power： | 100w | 100w | 150w |
| Input voltage： | AC100-277V | AC100-277V | AC100-277V |
| Lumens： | 5500-6000lm | 11000-12000lm | 16500-18000lm |
| efficiency： | 120lm/W | 120lm/W | 120lm/W |
| CCT： | 3000-6500K | 3000-6500K | 3000-6500K |
| CRI | ≥80ra | ≥80ra | ≥80ra |
| Beam Angle： | 60°/60*120°/80*155 | 60°/60*120°/80*155 | 60°/60*120°/80*155 |
| Light source： | Philips-3030LED | Philips-3030LED | Philips-3030LED |
| LED Qty： | 64PCS | 128PCS | 192PCS |
| Weight: | 2.6KG | 3.8KG | 5KG |
| Rating： | IP65 | IP65 | IP65 |
| Model： | WD-YSLTL200W-B04 | WD-YSLTL250W-B05 | More |
| Lamp type： | Outdoor | Outdoor | |
| Rated power： | 200w | 250w | |
| Input voltage： | AC100-277V | AC100-277V | |
| Lumens： | 21000-22000lm | 27500-3000lm | |
| efficiency： | 120lm/W | 120lm/W | |
| CCT： | 3000-6500K | 3000-6500K | |
| CRI | ≥80ra | ≥80ra | |
| Beam Angle： | 60°/60*120°/80*155 | 60°/60*120°/80*155 | |
| Light source： | Philips-3030LED | Philips-3030LED | |
| LED Qty： | 256PCS | 320PCS | |
| Weight: | 6.0KG | 7.2KG | |
| Rating： | IP65 | IP65 |
- Carton size：350*310*210mm
- Package Qty：1 PCS
- G.W: 3.9 KG
- Product working voltage is AC100~277V,50/60Hz，Please do not exceed the working voltage range.
- The lamp cannot be used in violation of any fire regulations.
- Input product line, brown is “L”, blue is “N”, yellow-green is GND.
- Be sure wiring is closed and prevent leakage when installing.
- Be sure to disconnect power before installing, don’t construction with electricity.
Installation and schematic.
-
