American Style 100W LED wall pack light, AD12 Aluminum Die Casting

100W LED wall pack light

  • Model: WD-BD-AEH2
  • Input voltage: 277 (V)
  • Number of LED lamp beads: 140
  • Packaging process: patch type
  • LED chip brand: LUMILEDS
  • Luminous flux: 10000 (lm)
  • Color temperature: 3000-6500 (K)
  • Power factor: ≥ 0.9
  • Luminaire luminous efficiency: 100 (lm/w)
  • Color rendering index: ≥ 70
  • Luminous angle: 120 (degrees)

Wandan LED Product Details

  • Temperature rise: 40 (K)
  • Dimming: Yes
  • Housing material: aluminum
  • Life: 50000 (H)
  • Size: 322 * 132 * 161 (mm)
  • Certification: EU CE certification
  • Protection grade: IP65
  • Weight: 3200 (g)
  • Luminous angle:DLC4.3 standard light distribution/PC cover
  • Usage: walls, stairs, door heads
  • Scope of use: Outdoor wall lighting
  • Featured services: customization
  • Power: 40W, 60W, 100W
  • Warranty period: 5 years

High Efficiency: Wandan Lighting 100W LED wall pack light outputs 10,000 lumens of luminous performance light and is the perfect replacement for 600W metal halide lamp. The recommended mounting height is measured at 20-22ft. It is commonly used for outdoor security lighting, wall perimeter lighting, garages, backyards, factories, warehouses, workshops, etc.

Dusk to Dawn Photocell: The dusk to dawn Wandan 100 watt LED wall pack with photocell allows the illuminant to be turned ON at night (50±30 lx) and turned OFF at daytime (200±50 lx).

5-year Warranty & Long Lifespan: This outdoor waterproof 100w LED wall lights comprise a die-cast aluminum body with a commercial-grade powder-coated bronze finish, impact-resistant tempered glass lens, and a maintenance-free LED. They have a lifespan of up to 50,000 hours, which implies that if it works 8 hours per day, they can work for more than 17 years. And we also provide 5 years warranty.

UL Certifications: Wandan 100w LED wallpack is UL listed, you can use it with peace of mind without worrying about safety issues.

Easy Installation: Our 100W outdoor wall lights are easy to install. In case of any technical-related questions, please feel free to contact us, and our professional support team will get back to you within 24 working hours.

The Advantage Of American Style 100W LED wall pack light

The Advantage Of American Style 100W LED wall pack light
A.The whole lamp adopts high purity national standard ADC12 aluminum integrated die casting molding+brim design, European and American style, dignified and atmospheric
B.Adopting international first-class brand Philips light source with high luminous efficiency and low light attenuation, EMC process has excellent high-temperature resistance and U-IV resistance
C.The lens is made of imported Japanese Imperial PC raw materials, with a light transmittance of over 93%, and a more uniform light spot without glare
D.With both exposed and hidden mounting holes, installation is more convenient
Technology DataApplication Scenarioproducts sizeproduct Packaging
Products TypeWD-BD-AEH2-40W WD-BD – AEH2-60W WD-BD-AEH2-100W
Chips No84PCS126PCS154PCS
Luminous Efficiency 14OLM/W 14OLM/W 14OLM/W
Total luminous flux 560OLM 840OLM 140OOLM
Colour Temperature 3000-650OK 3000-650OK 3000-650OK
Input Voltage AC100-305v AC100-305v AC100-305v
