Wandan® Lighting has built a reputation for delivering top-quality LED light fixtures at competitive prices. Wandan offers you an extensive range of Industrial & Commercial lighting products with a wide variety of lighting solutions for indoor and outdoor use.Free Quote!

LED High Bay Light With Riveting Heat Pipe

Heat Pipe Lamp

  • Product model: WD-GK-MYA
  • Product power: 50W, 100W, 150W, 200W, 250W
  • Price advantage: source manufacturer, manufacturer direct sales
  • Quality assurance: independent research and development, patent protection
  • Product certification: 3C, CE, UL, etc
  • Technical support: free customized lighting design scheme
  • Applicable places: specially designed for factory lighting, it can be widely used in high-shed workshops, workshops, warehouses, exhibition halls of logistics centers, gymnasiums, shipyards, highway toll stations, gas stations, factories, supermarkets, farmers’ markets and other places requiring lighting.

Wandan LED Product Details

  • The anti-glare high transmittance PC light transmission cover is adopted, with high light transmittance; At the same time, the light is soft and not dazzling, and can be used in all lighting environments; Add silicone gasket to prevent dust intrusion.
  • Ultrabright imported large-area SMD LED chip has good color rendering and various light colors can be selected, which can meet the needs of different environments and eliminate the high color temperature of traditional lamps
  • The lampshade adopts the most advanced scale secondary light distribution technology, with the best optical distribution. The lamp output rate can reach more than 90%. The lampshade is divided into six sizes
  • Adopt heat pipe riveting technology, equipped with 24 pieces of ultra-thick aluminum cold-forged aluminum pipe heat dissipation module+red copper HID heat conduction system; The heat generated by the light source is transferred to the building modular radiator through the heat pipe. The heat dissipation speed and efficiency of the lamp body is more than 200% of that of the pure aluminum radiator, with high heat dissipation efficiency.
  • Industrial-grade multiple explosion-proof drive power box cover, high-purity die-cast aluminum, surface through anodic oxidation process, to achieve IP65 waterproof and dust-proof function while preventing oil pollution
  • Pure copper heat pipe heat dissipation technology is adopted. The copper pipe heat dissipation is the best among the known metals. The heat conduction copper pipe is in close contact with the heat source, and the heat dissipation effect is good
Technology DataAttention
【Product number】WD-GK-MY-A50WD-GK-MY-A100WD-GK-MY-A150
【Product wattage】50W100W150W
【size】Diameter 350*240mmDiameter 350*height 270mm Diameter 410*height 300mm
【Color temperature】3000K-6500K3000K-6500K3000K-6500K
【Irradiation angle】60°/90°/120°60°/90°/120°60°/90°/120°
【Power Solution】Isolated constant current driveIsolated constant current driveIsolated constant current drive
【chip】Sanan 3030 high lumen PhilipsSanan 3030 high lumen PhilipsSanan 3030 high lumen Philips
【Service life】50000 hours50000 hours50000 hours
【Protection level】IP65IP65IP65
【Installation method】Hanging chain/boom/bracketHanging chain/boom/bracketHanging chain/boom/bracket
【Certification level】3C certification3C certification3C certification
【Warranty】3 years3 years3 years
【Product number】WD-GK-MY-A200WD-GK-MY-A250More
【Product wattage】200W250W
【size】Diameter 350*height 350mm Diameter 350*height 400mm
【Color temperature】3000K-6500K3000K-6500K
【Irradiation angle】60°/90°/120°60°/90°/120°
【Power Solution】Isolated constant current driveIsolated constant current drive
【chip】Sanan 3030 high lumen PhilipsSanan 3030 high lumen Philips
【Service life】50000 hours50000 hours
【Protection level】IP65IP65
【Installation method】Hanging chain/boom/bracketHanging chain/boom/bracket
【Certification level】3C certification3C certification
【Warranty】3 years3 years
  • Product working voltage is AC100~277V,50/60Hz,Please do not exceed the working voltage range.
  • The lamp cannot be used in violation of any fire regulations.
  • Input product line, brown is “L”,  blue is “N”, yellow-green is GND.
  • Be sure wiring is closed and prevent leakage when installing.
  • Be sure to disconnect power before installing, don’t construction with electricity.

Our LED high bay light including linear high bay, round high bay adopts new materials(graphene) and new technology(POB). The light efficacy is up to 160lm/W~190lm/W, which is ideal replacements for 250W~600W metal halide fixtures. Intelligent control can be supported to provide the energy-efficient solution for your factories, warehouses, hangars, etc.
High-quality Led street light wholesale from Wandan Lighting. Contact us for preferential price from leading led street light manufacturer in China. There are three types in LED street light with new technology, isolated driver, integrated driver and solar system. All of them adopts 3030 or 5050 LED chip and professional roads lighting optical lens with high efficiency(160lm/W) and uniform light. Various wattages from 10W to 500W, which suitable for 3-12M poles, and kinds of roads lighting, including the off-grid area.
LED Flood Light is designed for outdoor and indoor lighting purpose, and helps to improve visibility, enhance safety, and cut down energy consumption. Innovations and leading technologies can always be found in every of the flood lights, and that’s exactly what forms their unrivaled performance. Choose from Wandan portfolios, light better, save remarkably, and enjoy the great durability.
Wandan Lighting offer popular led stadium lights to meet the different types led lighting demand of the gymnasium (football, basketball, baseball, tennis, soccer) and the arena applications, keeping enough light to illuminate these sport places while reducing the light scattering that causes light pollution. The led lights save up to 88% in energy consumption and last more than 60,000 hours. High-quality radiators reduce heat generation, thus reducing the load on air conditioners. What's more, the 4000k color temperature and 5000K white color temperature are the favorite bright options.
