Louver Type LED High Bay Light

Louver High Bay Light

  • Product model: WD-LD-MO
  • Product power: 100W, 150W, 200W
  • Price advantage: source manufacturer, manufacturer direct sales
  • Quality assurance: independent research and development, patent protection
  • Product certification: 3C, CE, UL, etc
  • Technical support: free customized lighting design scheme
  • Applicable places: specially designed for factory lighting, it can be widely used in high-shed workshops, workshops, warehouses, exhibition halls of logistics centers, gymnasiums, shipyards, highway toll stations, gas stations, factories, supermarkets, farmers’ markets and other places requiring lighting.

Wandan LED Product Details

  • PC astigmatic plate, realizing the balance of high brightness and high uniformity, has the choice of 60 ° and 90 ° high-purity aluminum reflective cup, and the high reflectivity meets the light distribution requirements, and is suitable for different occasions.
  • Super bright imported large-area SMD LED chip with high thermal conductivity, low light decay, pure light color and no ghost
  • The lampshade adopts pure aluminum spinning lampshade, anodizing, polishing and sandblasting process, with high reflection efficiency and beautiful appearance
  • Integrated design, providing high energy efficiency heat dissipation efficiency and high level IP/IK protection; Ensure that the lamp body works safely and reliably in the whole life of – 20 ℃ to+45 ℃.
  • Imported high-density gelatinized constant voltage and current driver is adopted, with power factor of more than 0.90 and power efficiency of more than 93%
  • The core SMD chip high luminous efficiency lamp bead can effectively play the LED luminous efficiency, high brightness, long life, energy saving and electricity saving.
  • Intelligent LED chip, with wide illumination range, longer range and strong light transmission, and service life up to 50000H
  • The louver type heat dissipation structure makes the hot air form left and right convection air ducts, and 3D three-dimensional heat dissipation further enhances the heat dissipation effect.
Technology DataAttention
【Product Number】WD-GK-MO-A100WD-GK-MO-A150WD-GK-MO-A200
【Color Temperature】3000K-6500K3000K-6500K3000K-6500K
【Irradiation Angle】60°/90°/120°60°/90°/120°60°/90°/120°
【Power Solution】Isolated constant current driveIsolated constant current driveIsolated constant current drive
【Chip】Sanan 3030 high lumen PhilipsSanan 3030 high lumen PhilipsSanan 3030 high lumen Philips
【Service Life】50000 hours50000 hours50000 hours
【Protection Level】IP65IP65IP65
【Installation Method】Hanging chain/boom/bracketHanging chain/boom/bracketHanging chain/boom/bracket
【Certification Level】3C certification3C certification3C certification
【Warranty】3 years3 years3 years
  • Product working voltage is AC100~277V,50/60Hz,Please do not exceed the working voltage range.
  • The lamp cannot be used in violation of any fire regulations.
  • Input product line, brown is “L”,  blue is “N”, yellow-green is GND.
  • Be sure wiring is closed and prevent leakage when installing.
  • Be sure to disconnect power before installing, don’t construction with electricity.

Our LED high bay light including linear high bay, round high bay adopts new materials(graphene) and new technology(POB). The light efficacy is up to 160lm/W~190lm/W, which is ideal replacements for 250W~600W metal halide fixtures. Intelligent control can be supported to provide the energy-efficient solution for your factories, warehouses, hangars, etc.
