Newest Ufo Led High Bay Light

100W-240W UFO LED High Bay Light

UFO LED High Bay Light 100w, 150w, 200w
Thick aluminum with aviation standard material
High lumen effect 130~140lm/w
Meanwell Driver & Wonder Driver optional
0~10V, DALI Dimmable Driver (Optional)
Chip: Philips 3030 LED
IP rating: IP65
60° & 90° Lens ， 120° PC Clean or Milk Cover
Excellent thermal management and Low maintenance
Warranty: 5 years

Wandan LED Product Details

Applications: Ideal for 6~10m warehouse lighting, factory lighting, and bay lighting replacement

Manufacturer of 160lm/w Ultrathin UFO LED High Bay Light for commercial and architectural applications. Canopy, high-bay, flood, gooseneck, parking, security, explosion and vapor proof lights are offered. Adapters, caps, brackets, aluminum and steel streetlight poles are also available.

Technology DataApplication PlacesPackageAttentionlED Light DimensionsDifferent install method

Model：	WD-UFO100W-C1	WD-UFO100W-C2	WD-UFO100W-C3
Power:	100W±3%	150W±3%	200W±3%
Working voltage：	AC100-277V	AC100-277V	AC100-277V
Led Source:	Philips-3030 LED	Philips-3030 LED	Philips-3030 LED
Led Qty:	119 PCS	180 PCS	260 PCS
Beam angle:	60°/90°/120°	60°/90°/120°	60°/90°/120°
Lumen：	130~140lm/W	130~140lm/W	130~140lm/W
Life span	50 000h	50 000h	50 000h
Power Factor:	≥0.95	≥0.95	≥0.95
Correlated Color Temperature：	3000K / 4000K / 6000k	3000K / 4000K / 6000k	3000K / 4000K / 6000k
CRI：	>80Ra	>80Ra	>80Ra
Certificate:	CE ROHS	CE ROHS	CE ROHS
IP Rating:	IP65	IP65	IP65
Warranty:	5 years	5 years	5 years
Weight:	1.97 KG	2.62 KG	3.03 KG

Carton size：425*425*230 mm
Package Qty：1 PCS
G.W: 7 KG
Packing tips

Carton size：425*425*230 mm
Package Qty：1 PCS
G.W: 7 KG
Packing tips

Product working voltage is AC100~277V,50/60Hz，Please do not exceed the working voltage range.
The lamp cannot be used in violation of any fire regulations.
Input product line, brown is “L”, blue is “N”, yellow-green is GND.
Be sure wiring is closed and prevent leakage when installing.
Be sure to disconnect power before installing, don’t construction with electricity.

Our LED high bay light including linear high bay, round high bay adopts new materials(graphene) and new technology(POB). The light efficacy is up to 160lm/W~190lm/W, which is ideal replacements for 250W~600W metal halide fixtures. Intelligent control can be supported to provide the energy-efficient solution for your factories, warehouses, hangars, etc.
