50Hz Explosion-Proof Emergency Sign Light

LED Light For Parking Lot

  • Product model: WD-FB-BZ
  • Explosion-proof sign: EX Ⅱ BT6
  • Price advantage: source manufacturer, manufacturer direct sales
  • Quality assurance: independent research and development, patent protection
  • Product certification: 3C, CE, UL, EX, etc
  • Technical support: free customized lighting design scheme
  • Applicable place: specially designed for explosion-proof lighting, it can be widely used in industrial and environmental harsh places such as chemical plants, warehouses, gas stations, engineering tunnels, oil mining and smelting, and scene lighting.

Wandan LED Product Details

  • Prey, wafer and other chips are used. The chip uses excellent bright LED beads with high brightness, good color rendering, and low light decay. The chip has pure light color, low heat, and long service life
  • Adopt high borosilicate tempered glass products, oil-plated screen printing panel, thickened tempered glass with high resistance to 4J impact and high temperature.
  • The aluminum alloy die-casting is formed at one time to speed up the heat dissipation; The shell is polished, with smooth surface and high-voltage electrostatic spraying treatment, IP65 protection level and WF1 anti-corrosion; High safety level.
  • The specially designed internal circuit has multiple functions such as overcharge protection, short circuit protection, over-discharge protection, etc., effectively ensuring the use performance
  • Stainless steel exposed mounting hardware, light angle can be adjusted freely, easy to operate and use
  • IP65 waterproof and moisture-proof, suitable for explosive gas environment, explosive dust environment and other harsh environments
  • The specially designed internal circuit has multiple functions such as overcharge protection, short circuit protection, over-discharge protection, etc., effectively ensuring the use performance
  • The exposed fastener of the lamp is made of high-quality stainless steel and installed with rubber gasket, which is reliable in sealing, waterproof, dust-proof and corrosion-proof.
  • The aluminum alloy die-casting is formed at one time to speed up the heat dissipation; The shell has been polished, and the surface is smooth, and the surface is treated with high-voltage electrostatic spraying plastic, WF1 anti-corrosion; High safety level.
Technology DataAttention
【Product number】WD-FB-BZAWD-FB-BZB
【product name】Explosion-proof emergency lighting sign lampExplosion-proof sign lights
【size】Length 260*Width 220*Height 70mmLength 260*Width 220mm
【Voltage】AC220V-50HzAC220V-50Hz
【Emergency Time】≥90 minutes≥90 minutes
【Response time】0.3 seconds0.3 seconds
【Charging time】24H24H
【Power Solution】Isolated constant current driveIsolated constant current drive
【Explosion-proof mark】EXⅡBT6EXⅡBT6
[anti-corrosion lamp level]WF1WF1
【chip】Preh, Epistar, PhilipsPreh, Epistar, Philips
【Service life】50000 hours50000 hours
【Installation method】Pedestal type, wall type, ceiling typePedestal type, wall type, ceiling type
【Warranty】3 years3 years
  • Product working voltage is AC100~277V,50/60Hz,Please do not exceed the working voltage range.
  • The lamp cannot be used in violation of any fire regulations.
  • Input product line, brown is “L”,  blue is “N”, yellow-green is GND.
  • Be sure wiring is closed and prevent leakage when installing.
  • Be sure to disconnect power before installing, don’t construction with electricity.
