Linear LED High Bay Light
- Product model: WD-GK-XA
- Product power: 50W, 100W, 150W, 200W, 250W
- Price advantage: source manufacturer, manufacturer direct sales
- Quality assurance: independent research and development, patent protection
- Product certification: 3C, CE, UL, etc
- Technical support: free customized lighting design scheme
- Applicable places: specially designed for industrial lighting, widely used in office buildings, logistics parks, workshops, workshops, warehouses, highway toll stations, gas stations, shopping malls, supermarkets, exhibition halls, gymnasiums and other large halls.
Wandan LED Product Details
- Using CREE/LUMILEDS3030 SMD lamp beads, high CRI, fast heat conduction, low light decay, stable quality and performance, high luminous efficiency, and more energy-saving
- PC optical material lens, high light transmittance, impact resistance, 30 ° 60 ° 90 ° 60 ° * 120 ° four angle options to meet the needs of light distribution
- Adopt integral molding die-casting process, precise plasticity, large heat dissipation area, good thermal conductivity
- The installation irradiation angle is more flexible, and the lamp bracket is made of cold-rolled steel plate, which has high strength, safety and reliability;
- The power supply is designed with a constant voltage and constant current circuit, the power factor is above 0.90, the power efficiency is above 90%, and it can save energy by more than 60% compared with the sodium lamp
- Precision cast aluminum, strong and durable, 360° air convection design, large heat dissipation area, good air convection, light weight
- Voltage stabilized constant current driver, power factor above 0.90, power supply efficiency above 90%, compared with sodium lamps, it can save energy by more than 60%
【Product number】 | WD-GK-XA50 | WD-GK-XA100 | WD-GK-XA150 |
【Product wattage】 | 50W | 100W | 150W |
【size】 | 353*144*115mm | 620*144*115mm | 887*144*115mm |
【Voltage】 | AC220V-50Hz | AC220V-50Hz | AC220V-50Hz |
【lumen】 | 6000lm | 12000lm | 18000lm |
【Color temperature】 | 3000K-6500K | 3000K-6500K | 3000K-6500K |
【Irradiation angle】 | 30°/60°/90°/120° | 30°/60°/90°/120° | 30°/60°/90°/120° |
【Power Solution】 | Isolated constant current drive | Isolated constant current drive | Isolated constant current drive |
【chip】 | Sanan 3030 high lumen Philips | Sanan 3030 high lumen Philips | Sanan 3030 high lumen Philips |
【Service life】 | 50000 hours | 50000 hours | 50000 hours |
【Protection level】 | IP65 | IP65 | IP65 |
【Installation method】 | Chains/Brackets | Chains/Brackets | Chains/Brackets |
【Certification level】 | 3C certification | 3C certification | 3C certification |
【Warranty】 | 3 years | 3 years | 3 years |
【Product number】 | WD-GK-XA200 | WD-GK-XA250 | More |
【Product wattage】 | 200W | 250W | |
【size】 | 1154*144*115mm | 1421*144*115mm | |
【Voltage】 | AC220V-50Hz | AC220V-50Hz | |
【lumen】 | 24000lm | 30000lm | |
【Color temperature】 | 3000K-6500K | 3000K-6500K | |
【Irradiation angle】 | 30°/60°/90°/120° | 30°/60°/90°/120° | |
【Power Solution】 | Isolated constant current drive | Isolated constant current drive | |
【chip】 | Sanan 3030 high lumen Philips | Sanan 3030 high lumen Philips | |
【Service life】 | 50000 hours | 50000 hours | |
【Protection level】 | IP65 | IP65 | |
【Installation method】 | Chains/Brackets | Chains/Brackets | |
【Certification level】 | 3C certification | 3C certification | |
【Warranty】 | 3 years | 3 years |
- Product working voltage is AC100~277V,50/60Hz,Please do not exceed the working voltage range.
- The lamp cannot be used in violation of any fire regulations.
- Input product line, brown is “L”, blue is “N”, yellow-green is GND.
- Be sure wiring is closed and prevent leakage when installing.
- Be sure to disconnect power before installing, don’t construction with electricity.
-
